100,000-Object Editor & Virtualized Tree

100,000-Object Editor / Virtualized Tree

Use this document as a staff-level interview reference for a data-heavy frontend system such as:

• A Figma-like editor
• Adobe Express or Firefly editor
• A layer tree with 100,000 objects
• A dashboard with large hierarchical datasets
• A canvas-based creative application

---

1. Example Interview Prompt

Design the frontend architecture for a browser-based creative editor containing up to 100,000 objects. Users can pan, zoom, select, drag, resize, reorder layers, search objects, and undo or redo changes. The editor must remain responsive during common interactions.

A strong answer should separate:

1. The document model
2. The React application shell
3. The interaction controller
4. The rendering engine
5. The virtualized layer tree
6. Worker-based computation
7. Persistence and collaboration

---

2. Requirements

Functional Requirements

• Load a document containing up to 100,000 objects
• Pan and zoom the canvas
• Select one or multiple objects
• Drag, resize, rotate, hide, lock, and reorder objects
• Support text, images, vectors, groups, and nested layers
• Search the document hierarchy
• Display a virtualized layer tree
• Undo and redo edits
• Autosave changes
• Load assets progressively
• Optionally support real-time collaboration

Non-Functional Requirements

• Target 60 FPS during common interactions
• Input response should usually remain below 100 ms
• Large documents should become incrementally interactive
• Memory usage must remain bounded
• The editor must be keyboard-accessible
• Assistive technology must understand selection and object hierarchy
• The system must recover from worker, rendering, asset, and save failures
• Unsaved work must never be silently discarded

Scale Assumptions

100,000 logical document objects
20–200 objects typically visible
1,000–5,000 visible in a worst-case zoom level
10,000+ expanded rows in the layer tree
Pointer events may arrive faster than display refresh
Autosave occurs every few seconds
Large binary assets are served from object storage through a CDN

The first important observation is:

The system must not create 100,000 React components or DOM nodes.

---

3. High-Level Frontend Architecture

┌──────────────────────────────── Browser ───────────────────────────────┐
│                                                                       │
│  React Application Shell                                             │
│  ┌─────────────┐ ┌────────────────────┐ ┌─────────────────────────┐  │
│  │ Toolbar     │ │ Virtualized Layers │ │ Properties Panel        │  │
│  │ Menus       │ │ Tree               │ │ Selection Controls      │  │
│  └─────────────┘ └────────────────────┘ └─────────────────────────┘  │
│                         │                                             │
│                 Command / Interaction Layer                           │
│                         │                                             │
│  ┌──────────────────────▼──────────────────────────────────────────┐  │
│  │ Client Document Store                                          │  │
│  │ objectsById • selection • viewport • history • revisions       │  │
│  └─────────────┬──────────────────────────┬────────────────────────┘  │
│                │                          │                           │
│       ┌────────▼────────┐        ┌────────▼────────────────┐          │
│       │ Spatial Index   │        │ Web Worker              │          │
│       │ R-tree/quadtree │        │ parsing/search/geometry │          │
│       └────────┬────────┘        └────────┬────────────────┘          │
│                │                          │                           │
│       ┌────────▼──────────────────────────▼───────────────────────┐   │
│       │ Canvas / WebGL Rendering Engine                          │   │
│       │ culling • batching • hit testing • LOD • texture cache   │   │
│       └───────────────────────────────────────────────────────────┘   │
│                                                                       │
│  Accessible DOM control plane                                        │
│  layer tree • selection summary • property controls • live regions    │
└───────────────────────────────────────────────────────────────────────┘

Core Architectural Principle

React owns the product UI. It should not own every high-frequency pixel update.

Use React for:

• Toolbar
• Menus
• Dialogs
• Properties panel
• Search
• Layer tree
• Network and save indicators

Use an external renderer for:

• Scene drawing
• Pan and zoom
• Selection overlays
• Drag previews
• Hit testing
• Level-of-detail rendering
• Texture and geometry caches

---

4. Core Data Model

Use normalized state instead of a deeply nested mutable object tree.

type ObjectId = string;

type EditorObject = {
  id: ObjectId;
  type: 'text' | 'image' | 'shape' | 'group';

  parentId: ObjectId | null;
  childIds?: ObjectId[];

  x: number;
  y: number;
  width: number;
  height: number;
  rotation: number;

  zIndex: number;
  hidden: boolean;
  locked: boolean;

  version: number;
};

type DocumentState = {
  objectsById: Map<ObjectId, EditorObject>;
  rootIds: ObjectId[];

  selectedIds: Set<ObjectId>;
  primarySelectedId: ObjectId | null;

  viewport: {
    x: number;
    y: number;
    zoom: number;
    width: number;
    height: number;
  };

  documentRevision: number;
};

Why Normalized State

• Fast lookup by ID
• Update one object without cloning a deep tree
• Easier operation-based undo
• Easier collaboration
• Easier spatial-index updates
• Easier incremental persistence
• Stable selection independent of row mounting

---

5. State Ownership

React state
- dialogs
- toolbar mode
- panel state
- search query
- loading indicators

Document store
- normalized objects
- selection
- document revision
- undo history
- dirty operations

Mutable interaction controller
- current pointer position
- hover target
- drag transform
- resize gesture
- temporary snap guides

Rendering engine
- visible object cache
- tiles
- geometry buffers
- textures
- viewport render state

High-frequency gesture state should not trigger global React rerenders.

---

6. Rendering Strategy

DOM or SVG

Best for:

• Accessibility
• Native semantics
• CSS styling
• Small or moderate object counts
• Simple interaction

Problems at 100,000 objects:

• Large DOM memory
• Expensive style calculation
• Layout and paint invalidation
• Large accessibility tree
• React reconciliation overhead
• Event-listener overhead

Canvas 2D

Best for:

• Moderate visible object count
• Images, text, and basic vector drawing
• Simpler implementation
• Strong browser support
• Faster iteration

Limitations:

• CPU-bound drawing
• Complex compositing can become expensive
• Limited batching control
• Heavy filters may miss frame budgets

WebGL

Best for:

• Dense visible scenes
• GPU batching
• Image compositing
• Shaders and effects
• Smooth transforms
• High object throughput

Limitations:

• More complex implementation
• Text rendering is harder
• GPU memory management
• Context-loss recovery
• Device and driver variation
• Accessibility still requires DOM

Recommended Decision

Use React for the application shell, a virtualized DOM tree for layers, and Canvas or WebGL for the main scene. Start with Canvas 2D unless profiling or product effects justify WebGL.

---

7. Viewport Culling

Do not draw all 100,000 objects.

Maintain a spatial index such as an R-tree or quadtree.

Viewport changes
    ↓
Convert screen viewport to world coordinates
    ↓
Query spatial index
    ↓
Return visible object IDs
    ↓
Add overscan
    ↓
Sort by z-order
    ↓
Render visible objects only

Example:

type Rectangle = {
  left: number;
  top: number;
  right: number;
  bottom: number;
};

function getVisibleObjects(viewport: Rectangle, spatialIndex: SpatialIndex): ObjectId[] {
  const overscanned = expandRectangle(viewport, 200);
  return spatialIndex.search(overscanned);
}

Complexity

Without spatial indexing:

O(N) per frame
N = 100,000

With an R-tree:

Approximately O(log N + K)
K = visible objects

The main design goal is:

Make frame cost proportional to visible work, not total document size.

---

8. Level of Detail

Do not render full detail at every zoom level.

Zoom < 5%
→ page or group thumbnails

Zoom 5–20%
→ object bounds and dominant colors

Zoom 20–75%
→ normal geometry and lower-resolution images

Zoom > 75%
→ full geometry, text, effects, and high-resolution assets

This reduces work for:

• Tiny text
• Shadows
• Filters
• Large images
• Complex paths
• Deeply nested groups

---

9. Interaction Architecture

Pointer events can arrive more frequently than the display can render.

Do not update React state on every pointer event.

let pendingPointerPosition: { x: number; y: number } | null = null;
let frameScheduled = false;

function onPointerMove(event: PointerEvent) {
  pendingPointerPosition = {
    x: event.clientX,
    y: event.clientY,
  };

  if (frameScheduled) return;

  frameScheduled = true;

  requestAnimationFrame(() => {
    frameScheduled = false;

    if (pendingPointerPosition) {
      applyDragFrame(pendingPointerPosition);
    }
  });
}

Drag Flow

pointerdown
→ begin transaction

pointermove
→ update transient transform
→ schedule one render per animation frame

pointerup
→ commit one operation
→ add to undo history
→ queue autosave

Benefits:

• Avoid hundreds of store updates
• Avoid hundreds of undo entries
• Reduce collaboration traffic
• Keep interaction latency low
• Limit rendering to display refresh rate

---

10. Hit Testing

Do not attach a handler to every canvas object.

Use delegated hit testing.

Pointer coordinate
    ↓
Convert screen point to world point
    ↓
Query spatial index for nearby candidates
    ↓
Sort by z-index
    ↓
Perform precise geometry test
    ↓
Select topmost matching object

Use two phases:

Broad Phase

• Bounding-box query
• R-tree or quadtree lookup

Narrow Phase

• Point in rotated rectangle
• Point in vector path
• Alpha test for images when necessary
• Shape-specific geometry test

---

11. Virtualized Layer Tree

The layer panel may represent tens of thousands of expanded rows.

Do not render the full hierarchy into the DOM.

Step 1: Flatten Visible Nodes

type FlatTreeRow = {
  id: ObjectId;
  depth: number;
  isExpanded: boolean;
  hasChildren: boolean;
};

function flattenVisibleTree(
  rootIds: ObjectId[],
  objectsById: Map<ObjectId, EditorObject>,
  expandedIds: Set<ObjectId>
): FlatTreeRow[] {
  const rows: FlatTreeRow[] = [];

  function visit(id: ObjectId, depth: number): void {
    const object = objectsById.get(id);
    if (!object) return;

    rows.push({
      id,
      depth,
      isExpanded: expandedIds.has(id),
      hasChildren: Boolean(object.childIds?.length),
    });

    if (!expandedIds.has(id)) return;

    for (const childId of object.childIds ?? []) {
      visit(childId, depth + 1);
    }
  }

  for (const rootId of rootIds) {
    visit(rootId, 0);
  }

  return rows;
}

Step 2: Render Only the Visible Window

For fixed-height rows:

function calculateWindow(
  itemCount: number,
  rowHeight: number,
  scrollTop: number,
  viewportHeight: number,
  overscan = 8
) {
  const firstVisible = Math.floor(scrollTop / rowHeight);
  const visibleCount = Math.ceil(viewportHeight / rowHeight);

  const start = Math.max(0, firstVisible - overscan);
  const end = Math.min(itemCount, firstVisible + visibleCount + overscan);

  return {
    start,
    end,
    offsetTop: start * rowHeight,
    totalHeight: itemCount * rowHeight,
  };
}

Even if there are 100,000 logical rows, the DOM may contain only 30–100 mounted rows.

---

12. Tree Interaction Design

Selection

Store selection by object ID, never by row index.

Indexes change when:

• Groups expand
• Groups collapse
• Search filters change
• Objects move
• Remote updates arrive

Keyboard Navigation

Support:

• Arrow up and down
• Arrow right to expand
• Arrow left to collapse or move to parent
• Home and End
• Shift for range selection
• Space or Enter to activate
• Type-ahead search

Focus

Virtualized rows may unmount.

Prefer:

• A persistent tree container
• aria-activedescendant
• Stable row IDs

Avoid depending on browser focus remaining on a recycled row.

---

13. Undo and Redo

Do not snapshot the entire document after every action.

Use operations or commands.

type EditorOperation =
  | {
      type: 'move';
      objectIds: ObjectId[];
      before: Record<ObjectId, { x: number; y: number }>;
      after: Record<ObjectId, { x: number; y: number }>;
    }
  | {
      type: 'update-properties';
      objectId: ObjectId;
      before: Partial<EditorObject>;
      after: Partial<EditorObject>;
    }
  | {
      type: 'delete';
      objects: EditorObject[];
    };

Undo applies the inverse operation.

Move:
before x=100, y=200
after  x=500, y=300

Undo:
restore before values

Redo:
reapply after values

Coalescing

100 pointer moves
→ one move command

20 keystrokes within 500 ms
→ one text-edit command

Benefits:

• Memory proportional to changed data
• Easier persistence
• Easier collaboration
• Easier replay and debugging

---

14. Web Workers

Use workers for CPU-heavy work that does not require DOM access.

Good worker tasks:

• Parse large document snapshots
• Rebuild spatial indexes
• Flatten large trees
• Search indexing
• Geometry calculations
• Thumbnail generation
• Image decoding where supported

Prefer incremental deltas over repeatedly cloning the entire document.

Main thread
→ sends operation delta

Worker
→ applies delta
→ updates index
→ returns compact derived result

---

15. Incremental Loading

Do not wait for the complete document before showing the editor.

1. Load application shell
2. Load document metadata
3. Load hierarchy and object bounds
4. Show low-detail scene
5. Load visible object details
6. Load nearby objects
7. Load offscreen objects lazily
8. Load high-resolution assets on demand

Separate:

• Structural metadata
• Geometry
• Style details
• Binary assets
• High-resolution variants

---

16. Performance Budgets

State explicit budgets in the interview.

Pointer-to-frame latency: target <16 ms
Typical interaction response: <100 ms
Viewport query: <5 ms
Visible scene render: <10 ms
Layer panel scroll: 60 FPS
Initial shell: <2 seconds
Document metadata interactive: <3 seconds
Long tasks: preferably below 50 ms

Measure:

• Frame duration
• Dropped frames
• Input latency
• React commit duration
• Visible object count
• Spatial-index query time
• Worker queue depth
• Texture memory
• Long tasks
• Time to document interactive

---

17. Deep-Dive Questions and Answers

---

17.1 Why Not Render Everything Once?

Rendering all 100,000 objects once does not mean the cost is paid only once.

The browser or renderer must still:

• Retain object state
• Track transforms
• Perform hit testing
• Repaint on viewport changes
• Maintain layout and style data for DOM/SVG
• Reconcile updates
• Keep accessibility metadata
• Consume memory

With DOM or SVG, the cost is especially high:

• Large DOM memory
• Style and layout overhead
• Paint invalidation
• React reconciliation cost
• Large accessibility tree
• More garbage collection work

With Canvas or WebGL, retaining all objects may be possible, but drawing all of them every frame is still wasteful.

Separate:

Logical objects
→ all 100,000 objects

Renderable objects
→ visible or near viewport

Detailed objects
→ close enough to require full resolution

Use viewport culling and a spatial index.

Without index: O(N)
With R-tree: approximately O(log N + K)

The staff-level principle:

Keep the full document logically available, but bound rendering, layout, and interaction work by what the user can perceive.

---

17.2 What If an Offscreen Layer Is Selected?

Selection must not depend on whether an object or tree row is rendered.

type SelectionState = {
  selectedIds: Set<string>;
  primarySelectedId: string | null;
};

When an offscreen object is selected:

1. Update selection state immediately
2. Resolve object bounds
3. Reveal the object in the canvas if appropriate
4. Expand necessary ancestors in the layer tree
5. Scroll the virtualized tree to the row
6. Update accessible focus after the row mounts

Possible API:

editor.revealObject(objectId, {
  align: 'center',
  animate: true,
  padding: 80,
});

Important distinction:

Selection
→ durable editor state

Visibility
→ derived viewport state

Focus
→ accessibility and interaction state

Do not represent all three with one variable.

---

17.3 How Do Variable Row Heights Work?

Fixed-height virtualization:

offset = index × rowHeight

Variable-height rows require:

• Estimated row height
• Measurement cache
• Prefix sums or cumulative offset structure
• Binary search from scrollTop to row index
• Scroll anchoring

Example:

type RowMeasurement = {
  height: number;
  measured: boolean;
};

const measurements = new Map<string, RowMeasurement>();

Use ResizeObserver to measure mounted rows.

For a large dynamic list, use a Fenwick tree or segment tree:

• Height update: O(log N)
• Prefix sum: O(log N)
• Offset lookup: O(log N)

Scroll Anchoring

When estimates change, preserve:

• First visible row ID
• Offset from viewport top

After measurement, adjust scrollTop to keep the same anchor in place.

Staff-level answer:

Use estimated heights, measure mounted rows, maintain cumulative offsets, binary-search the visible range, and preserve a scroll anchor when measurements change.

---

17.4 How Do You Expand a 50K-Child Group?

Do not synchronously:

• Flatten 50,000 rows
• Create 50,000 React elements
• Measure every row
• Build every thumbnail

Possible strategies:

Incremental Flattening

Process 1,000 children
→ yield
Process next 1,000

Use:

• Web Worker
• scheduler.postTask
• MessageChannel
• Carefully controlled chunking

Lazy Range Projection

Maintain subtree sizes and map logical row ranges without materializing all rows.

type IndexedTreeNode = {
  id: string;
  childIds: string[];
  visibleSubtreeSize: number;
};

Server-Paged Children

GET /layers/{groupId}/children?cursor=...&limit=500

Use when child metadata is not already local.

User Experience

1. Mark group expanded immediately
2. Render the first visible rows
3. Continue processing incrementally
4. Allow collapse at any time
5. Cancel obsolete expansion work

Use request IDs:

const requestId = ++latestExpansionRequestId;

if (requestId !== latestExpansionRequestId) {
  return;
}

Principle:

Expansion should update logical visibility immediately, while expensive derived work remains incremental, cancellable, and bounded by the visible range.

---

17.5 How Is Canvas Content Accessible?

Canvas is visually rich but semantically empty unless the application provides a DOM-based accessibility layer.

The architecture should be:

Canvas
→ pixels and visual rendering

DOM
→ semantics, focus, keyboard interaction, announcements

Use:

Layer Tree

<div role="tree">
  <div role="treeitem" aria-level="2" aria-expanded="true" aria-selected="true">Product image</div>
</div>

Selection Summary

Rectangle selected.
X 120, Y 80.
Width 320, height 200.
Unlocked and visible.

Accessible Property Controls

<label>
  X position
  <input type="number" />
</label>

Keyboard Alternatives

• Arrow keys to move
• Shift plus arrow for larger movement
• Delete to remove
• Keyboard resize
• Keyboard rotate
• Group and reorder shortcuts

Live Announcements

Moved rectangle to X 180, Y 240.
Three layers grouped.
Undo: image resize.

Do not announce every pointer movement.

Also support:

• Visible focus
• High contrast
• Reduced motion
• Browser zoom
• Non-color-only indicators
• Large interaction targets

---

17.6 What Changes for Collaboration?

Collaboration turns the editor into a replicated document model.

Updates come from:

• Local user operations
• Remote operations

Represent committed edits as operations:

type Operation = {
  operationId: string;
  actorId: string;
  baseRevision: number;
  type: string;
  payload: unknown;
  timestamp: number;
};

Optimistic Flow

User edits
→ apply locally
→ render immediately
→ send operation
→ server orders and validates
→ ACK or correction returns

Track:

• Confirmed server revision
• Pending local operations
• Remote operations
• Reconciliation state

Conflict Models

Possible approaches:

• Central ordered operation log
• OT for sequence-like editing
• CRDT for offline or multi-device merging
• Hybrid approach

Practical hybrid:

• OT or CRDT for text
• Last-writer-wins registers for scalar properties
• Ordered-list CRDT for layer ordering
• Server-authoritative validation for destructive operations

Presence Is Separate

Presence messages are ephemeral:

type PresenceMessage = {
  actorId: string;
  cursor?: { x: number; y: number };
  selectedIds?: string[];
  viewport?: Viewport;
  expiresAt: number;
};

Do not place cursor movement in the durable operation log.

Collaborative Undo

Undo should reverse the local user’s last eligible operation, not blindly revert global state.

Example:

User A moves object
User B changes color
User A presses undo

Undo should restore position only.

Reconnection

1. Send last acknowledged revision
2. Receive missed operations or a snapshot
3. Reapply pending local operations
4. Resolve rejected or transformed operations
5. Resume presence separately

---

17.7 How Do You Avoid Stale Worker Results?

Workers introduce asynchronous races.

Example:

Worker starts calculation for revision 10
User updates document to revision 11
Worker returns revision 10 result

Every request should include versions.

type WorkerRequest = {
  requestId: string;
  documentRevision: number;
  viewportRevision?: number;
  payload: unknown;
};

type WorkerResponse = {
  requestId: string;
  documentRevision: number;
  result: unknown;
};

Before applying:

if (response.documentRevision !== currentDocumentRevision) {
  return;
}

For multiple dimensions:

type RevisionVector = {
  document: number;
  viewport: number;
  filter: number;
};

Use:

• Latest-wins request IDs
• Incremental ordered deltas
• Revision acknowledgements
• Cooperative cancellation
• Immutable snapshots
• Idempotent application

Latest-wins example:

let latestRequestId = 0;

function requestWork() {
  const requestId = ++latestRequestId;
  worker.postMessage({ requestId });
}

function handleResult(result: { requestId: number }) {
  if (result.requestId !== latestRequestId) return;
  apply(result);
}

Principle:

Every asynchronous result must prove that it was computed from the state version the UI still cares about.

---

17.8 How Do You Recover After WebGL Context Loss?

WebGL contexts may be lost because of:

• GPU resets
• Driver failures
• Memory pressure
• Browser resource reclamation
• Too many contexts

Listen for:

canvas.addEventListener('webglcontextlost', (event) => {
  event.preventDefault();
  pauseRenderer();
});

canvas.addEventListener('webglcontextrestored', () => {
  restoreRenderer();
});

GPU state must be treated as a disposable cache.

The durable source of truth remains:

• Document model
• Asset references
• Geometry descriptors
• Viewport state
• Render settings

Rebuild:

• Shaders
• Programs
• Buffers
• Textures
• Framebuffers
• Atlases

Recovery flow:

context lost
→ stop render loop
→ preserve editor state
→ show recovery indicator
→ queue or reject GPU work

context restored
→ recreate shaders
→ recreate buffers
→ restore visible textures first
→ draw basic scene
→ lazily restore offscreen resources
→ resume rendering

Fallback options:

• Reduced Canvas 2D mode
• Disable expensive effects
• Preserve unsaved operations
• Ask the user to reload only as a last resort

Principle:

GPU resources are disposable. The document and render descriptors must be sufficient to rebuild them.

---

17.9 How Do You Bound Memory?

Memory can grow in:

• Document model
• React components
• Spatial index
• Undo history
• Decoded images
• GPU textures
• Worker copies
• Search indexes
• Collaboration history
• Thumbnails
• Event listeners

Set budgets per category.

Document Model

• Normalize objects
• Avoid deep duplication
• Separate asset binaries
• Avoid retaining old object copies
• Intern repeated strings when useful

Render Cache

Retain detailed resources only for:

• Visible objects
• Nearby overscan
• Recently used objects

Use byte-based LRU eviction.

type CacheEntry = {
  key: string;
  byteEstimate: number;
  lastUsedAt: number;
};

Image Memory

A compressed image may decode to much more memory.

4,000 × 4,000 × 4 bytes
≈ 64 MB decoded

Use:

• CDN size variants
• Zoom-based decode resolution
• Thumbnail versions
• Decode concurrency limits
• Explicit ImageBitmap cleanup

GPU Memory

Estimate texture size:

width × height × bytes per pixel × mipmap factor

Use:

• Lazy upload
• Texture atlases
• Resolution tiers
• Explicit deletion
• Eviction under pressure

gl.deleteTexture(texture);
gl.deleteBuffer(buffer);

Undo History

• Store inverse operations
• Group old operations
• Create checkpoints
• Cap by bytes, count, or age

Worker Memory

Avoid repeated structured cloning.

Prefer:

• Incremental deltas
• Transferable ArrayBuffer
• Shared immutable structures where safe
• One canonical worker copy

Pressure Response

1. Evict offscreen high-resolution textures
2. Drop thumbnails
3. Reduce overscan
4. Lower image resolution
5. Compact undo history
6. Pause prefetching
7. Disable expensive effects

Principle:

Every cache needs an owner, a byte budget, an eviction policy, and lifecycle cleanup.

---

17.10 When Do You Choose Canvas vs WebGL?

Do not decide only from total object count.

Consider:

• Number of visible objects
• Complexity of effects
• Frequency of scene changes
• Amount of compositing
• Device targets
• Team expertise
• Importance of text rendering
• Time-to-market

Choose Canvas 2D When

• Visible object count is moderate
• Basic shapes, text, and images dominate
• CPU rendering meets the frame budget
• Simpler implementation matters
• Fast product iteration matters
• Shader effects are not required

Advantages:

• Simpler API
• Easier debugging
• Easier text rendering
• Lower engineering cost
• Strong compatibility

Choose WebGL When

• Many objects are visible
• Image compositing is heavy
• GPU effects are required
• Continuous transformations must remain smooth
• Instancing and batching matter
• Canvas profiling shows CPU rendering is the bottleneck

Advantages:

• GPU acceleration
• Efficient transforms
• Instancing
• Shader-based effects
• Better dense-scene scaling

Hybrid Approach

WebGL
→ main scene, effects, image compositing

Canvas 2D
→ overlays, special tools, fallback

DOM/SVG
→ text editing, controls, accessibility

A renderer abstraction makes migration easier:

interface SceneRenderer {
  setViewport(viewport: Viewport): void;
  applyChanges(changes: SceneChange[]): void;
  render(): void;
  hitTest(point: Point): ObjectId | null;
  dispose(): void;
}

Decision principle:

Canvas is usually the lower-complexity default. WebGL is justified when measured visible-scene density, effects, or compositing exceed the CPU frame budget.

---

18. Failure Handling

Worker Crash

• Restart worker
• Rebuild from latest revision
• Replay incremental operations
• Temporarily fall back to simpler calculations

Asset Failure

• Render placeholder
• Retry with backoff
• Do not block the whole scene
• Preserve layout bounds to avoid jumps

Save Failure

• Keep local operation queue
• Show unsaved state
• Retry idempotently
• Clear unsaved state only after server acknowledgement

Rendering Failure

• Preserve document state
• Reinitialize renderer
• Restore visible content first
• Fall back to reduced mode when necessary

---

19. Staff-Level Tradeoffs

The important design decisions are:

• Do not render 100,000 React or DOM nodes
• Separate React UI from high-frequency scene rendering
• Separate transient interaction state from committed document state
• Make rendering proportional to visible objects
• Use a spatial index for culling and hit testing
• Virtualize the tree independently from canvas rendering
• Use workers for expensive derived computation
• Keep accessibility in a semantic DOM control layer
• Use operations for undo, autosave, replay, and collaboration
• Add WebGL only when profiling justifies the complexity
• Define performance and memory budgets explicitly
• Design every cache with eviction and ownership

---

20. Two-Minute Interview Answer

I would avoid representing 100,000 objects as React or DOM nodes. React would own the application shell, toolbar, properties panel, search, and virtualized layer tree, while a dedicated Canvas or WebGL renderer owns the creative scene.

The document would be normalized by object ID. I would maintain a spatial index such as an R-tree so each viewport update queries only visible objects. That changes rendering work from O(N) over the full document to approximately O(log N + K), where K is the number of visible objects.

High-frequency interactions such as dragging would bypass React state. Pointer events update a transient interaction controller, rendering is scheduled once per animation frame, and pointer-up commits one operation to the document store, undo history, and autosave queue.

The layer panel would flatten only expanded nodes and virtualize rows, so even a 100,000-node hierarchy produces only dozens of mounted DOM elements. Selection remains stable by object ID, and accessibility is exposed through a semantic DOM control plane using a tree, property controls, keyboard commands, and live announcements.

Workers handle parsing, geometry, search, spatial-index updates, and large-tree flattening. Every worker result carries document and viewport revisions so stale results are ignored.

I would define explicit performance, memory, and reliability budgets, recover from worker or WebGL failures, and start with Canvas 2D unless profiling proves that WebGL is required for scene density or effects.

---

21. Short Whiteboard Flow

Use this order during the interview:

1. Clarify requirements and scale
2. Identify the main bottleneck
3. Separate React, store, interaction controller, and renderer
4. Normalize the document model
5. Add spatial indexing and viewport culling
6. Explain virtualized tree behavior
7. Explain drag, hit testing, and undo
8. Cover accessibility
9. Cover workers and stale-result protection
10. Cover collaboration
11. Cover memory and failure recovery
12. Finish with metrics and tradeoffs

---

22. Staff-Level Closing Statement

The goal is not merely to apply virtualization. The goal is to define where state lives, ensure work is proportional to what the user can perceive, isolate high-frequency rendering from React, preserve accessibility, and make the system observable, recoverable, and evolvable.
